Single Mode 8-Core MPO Female (APC) to MPO Female (APC) / to LC (PC) SMF 9/125μ Trunk Cable, by OS2 10g Communication

Overview Package size per unit product 1.00cm * 1.00cm * 1.00cm Gross weight per unit product 1.000kg Product Descriptio

Send inquiry

Basic Info

Model NO.	MPO-MPO-LC-OS2-B
Material Shape	Round Wire
Allowed Tensile Strength	<100N
Core	Multicore
Certification	RoHS, CE, ISO9001
Sheath Material	PVC
Transport Package	PE
Production Capacity	100000PCS/Year

Packaging & Delivery

Package size per unit product 1.00cm * 1.00cm * 1.00cm Gross weight per unit product 1.000kg

Product Description

8 Fiber Single Mode MPO Female (APC) to MPO Female (APC) / to LC (PC) Trunk Cable;
SMF 9/125μm, OS2 10G standard, LSZH -8 Core Fiber;
Each cable 100% tested for low insertion loss and back reflection;
Constructed with TYPE B (Chanel 1 to Chanel 12), Application for QSFP+ 40GBASE-PLR4 and QSFP28 100GBASE-PSM4 networks;
For QSFP+ Transceivers Link, Contact us for OEM or Custom;
Contact us for OEM customize and T/T payment;

Product Specifications

Connector A	MPO Female APC (pinless)	Connector B	MPO Female APC (pinless) / LC (PC)
Fiber Mode	8fibers OS2 9/125 μm	Wavelength	1310/1550 nm
Single Mode Class	OS2	RoHS Compliancy Status	Compliant
Polish Type	APC to APC or APC to LC	Minimum Bend Radius	7.5 mm
Insertion Loss	0.35 dB Max. (0.15 dB Typ.)	Return Loss	≥ 20 dB
Jacket OD	3.0 mm	Cable Jacket	LSZH
Installation Tensile Load	100 N	Long-Term Tensile Load	50 N
Storage Temperature	-40°C to 85°C	Operating Temperature	-10°C to 70°C

Overview:
MPO trunk cable, a cost-effective alternative to time-consuming field termination, is designed for high-density
fiber patching in data centers which need space saving and reduce cable management troubles. It is optimized for 40G
QSFP+ PLR4, 100G QSFP28 PSM4, 400G OSFP DR4/XDR4 and 400G QSFP-DD DR4/XDR4 optics direct connection and
high-density data center applications.

Specifications:
Connector A:MPO Female (Pinless)
Connector B:MPO Female (Pinless)
Fiber Mode:OS2 9/125μm SM
Wavelength:1310/1550nm
Polish Type:APC to APC
Minimum Bend Radius:10mm
Insertion Loss:0.35dB Max (0.15dB Typ.)
Return Loss:≥60dB
Attenuation at 1310nm:≤0.32 dB/km
Attenuation at 1550nm:≤0.18 dB/km
Jacket OD:3.0mm
Cable Jacket:LSZH
Installation Tensile Load:100 N
Long-Term Tensile Load:50 N
Operating Temperature:-10°C to +70°C
Storage Temperature:-40°C to +85°C

Applications:
40G QSFP+ PLR4
100G QSFP28 PSM4
400G OSFP DR4/XDR4
400G QSFP-DD DR4/XDR4
LR4 PSM 4*10Gbps
PSM4 4*25Gbps
DR4 4*100Gbps

Detailed Photos

Single Mode 8-Core MPO Female (APC) to MPO Female (APC) / to LC (PC) SMF 9/125μ Trunk Cable, by OS2 10g Communication
