3.0mm LSZH 12 Fibers 10g Om3 12 Strands MPO Fan out Cable

Basic Info

Model NO.	LW-MPO
Core	Multicore
Certification	RoHS, CE, ISO9001, VDE, CCC
Brand	OEM
Sheath Material	PVC
Keywords	MTP/MPO to LC/LC
Connector Type	MPO/MTP/LC/Dlc
Product Name	Duplex LC MPO-LC Harness Cables
Acket Materials	LSZH/Ofnr/PVC
3D Testing	100%
Jacket Colors	Yellow, Aqua , Erika Violet,Purple
Fiber Core	8 Core ,12 Core , 24 Core
Transport Package	Paper Box
Specification	1M 2M 3M
Trademark	LIGHTWIT
Origin	Shenzhen, China
HS Code	8544492900
Production Capacity	50000

Product Description

8f 12f 24f MTP/MPO to LC MPO-LC Harness Cables

Production Description
MPO-LC fan-out Cables are designed for high density applications with require high performance and speedy installation, also called MTP/MPO Breakout Cable or MTP/MPO Fanout Cable. The MTP/MPO breakout cables work from trunk backbone assemblies to fiber rack system in the high density backbone cabling. As terminated with MTP/MPO connectors on one end and standard LC/FC/SC/ST/MTRJ connectors (generally MTP to LC) on the other end, these cable assemblies can meet a variety of fiber cabling requirements.

Lightwit Photonics's fiber (core) counts are available in 8 to 144. We also provide Customized Service such as optional cable lengths to meet specific installation environments.

Cable structure
MTP Hybrid Harnesses Fiber Patch Cables are terminated with MPO connector on one end and other end with LC, FC, SC, ST, or MTRJ connectors to meet a variety of fiber cabling requirements.
1.The default diameter of the MTP cable is 3.0mm.
2.The diameter of branch cable could be choose as 0.9mm,2.0mm
3.Fiber-Mart can also custom the pulling eyes, welcome to contact us if you need.





Features
1.Polish Typle:UPC/APC
2.Fiber Typle:OS1/2,OM3,OM4 fiber grades(OM1 and OM2 available)
3.Fiber Count:8/12/24.,Specify
4.Cable/Pigtail Length:0.5m/2.0m/3.0m,.Specify
5.Polarity:Polarity A/Polarity B/Polarity C
6.MPO/MTP Connector Typle:Female/Male
7.Jacket Coating: PVC/LSZH
8. Connector Type: FC-UPC/FC-APC/LC-APC…specify

Application
Data communication network
Optical System Access network
Storage area networking fiber channel
High density architectures

Fiber Type	OS2,OM1,OM2,OM3,OM4,OM5
Fiber Count	8/12/24 cores
Cable Diamter	3.0mm 5.5mm or customized
Jacket Color	Yeloow, Orange, Aqua, Purple
Jacket Material	OFNR, OFNP, PVC, LSZH
Tensile Strength	500N
Operating Temperature	-20 to 70 ºC
Storage Temperature	-40 to 75ºC

Performance Level			Standard		Elite
Connector	Mode	Endface	IL(max) (dB)	RL(min) (dB)	IL(max) (dB)	RL(min) (dB)
MPO/MTP	SM	12F/APC	≤0.70	≥60	≤0.35	≥60
		24F/APC	≤0.75	≥60	≤0.35	≥60
		48F/APC	≤0.75	≥60
	MM	12F/PC	≤0.50	≥20	≤0.35	≥20
		24F/PC	≤0.50	≥20	≤0.35	≥20
		48F/PC	≤0.50	≥20

Note:
1.Test wavelength:[email protected]/1550nm,[email protected]/1300nm;
2.Standard conformance: GR-326,GR-1435.
