Sc/APC 4core Quadplex Flat Cable Patch Cord Pigtail with 2.0mm
SC/APC 4core Quadplex Flat Cable patch cord pigtail with 2.0mm Features Good durabilityGood exchangeabilityHigh temperat
Basic Info
Model NO. | SC APC |
Application | Communication, Sensor, Medicine, Probe |
Type | Single-mode Fiber |
Connection Structure | SC |
Material Shape | Flat Wire |
Allowed Lateral Pressure | 100(N/100mm)<1000(N/100mm) |
Allowed Tensile Strength | 100N<1000N |
Core | Multicore |
Sheath Material | PVC |
Transport Package | Carton |
Specification | 2.0mm |
Trademark | SMD |
Origin | Chian |
HS Code | 8544700000 |
Production Capacity | 200000/Month |
Product Description
SC/APC 4core Quadplex Flat Cable patch cord pigtail with 2.0mmFeatures
Good durabilityGood exchangeabilityHigh temperature stabilityLow insertion loss and back reflection loss
Applications
Optical Distribution FrameComputer NetworksFiber Optic Communication SystemsOptical Access NetworksLocal Area NetworkFiber Optic Sensors
Order Information
Cable Material: PVC, LSZH (LSOH), OFNR Cable Diameter: 3.0mm, 2.0mm, 0.9mm, 3.0*2.0mm, 5.0*2.0mm.. Fiber Type: SM 9/125um, MM 50/125um, MM 62.5/125um, 10G OM3(50/125um) Polishing: PC, UPC, APC. Length: 0.2m, 0.3m,.... 100m
Parameters
Single mode (9/125) Max Insertion Loss: 0.3dB Minimum Return Loss: PC: 50dB APC: 60dB
Technical specifications
Pigtail Connector | PC (SM) | UPC (SM) | APC (SM) | MM |
Return Loss (dB) | ≥45 | ≥50 | ≥60 | ≥35 |
Insertion Loss (dB) | ≤0.2 (max≤0.3) | |||
Repeatability (dB) | ≤0.1 | |||
Durability(1/Matings) | ≥500 | |||
Operation Temperature (°C) | -25~+70 | |||
Tensile Strength (N) | ≥90 (Φ3.0), ≥70 (Φ2.0), Φ0.9 | |||
Fiber | 9/125um, 50/125um,62.5/125um,ect | |||
diameter | 0.9mm 2.0mm, 3.0mm etc | |||
Cable material | PVC, LSZH | |||
Cores | Simplex, duplex, 4cores, 6cores, 8cores, 12cores etc |
FAQ
1.
Q: How can I get your quotation?
A: Please provide us informations as follows:
1. Item Number & Quantity.
2. Special Specification requirement.
3. Company Profile (Name, Tel, Fax, Address, and Webpage)
4. Any Other Relevant Details.
2.
Q: How can I get a sample to check your quality?
A: After price confirmation, you can require for samples to check our quality.
3.
Q: Terms of payment?
A: We accept payment as follows:
1).100% TT in advance.
2). 30% T/T deposit, 70% balance before delivery.
4.
Q: Can you do OEM?
A: Yes we can.
5.
Q: What about delivery time?
A: 1) Samples: within 3 days.
2) Goods: 3-7days usually.
